With the 2M Premounted, it’s never been easier to experience
The 2M Premounted is a practical and elegant solution for our customers who wish direct and easy mounting and replacement on their S-shaped tonearm. The quality of the SH-4 headshell is sturdy and rigid, yet the design emphasizes a slim and delicate form factor. The strong, lightweight headshell has an ergonomic design with a long finger lift that is easy to pick up.
Features:
- Mounted on our popular SH-4 Black headshell.
- Easy and direct mount on S-shaped tonearms with universal mount.
- Correct Baerwald alignment with tonearms with universal mount.
| Specifications | |
|---|---|
| Tracking ability at 315Hz at recommended tracking force | 80 µm |
| Frequency response | 20-20.000 + 2 / - 1 d |
| Channel separation | 15 kHz - 15 dB |
| Channel separation | 1 kHz - > 27 dB |
| Channel balance | 1 kHz - < 1 dB |
| Output voltage | 1000 Hz, 5cm/sec. - 5 mV |
| Compliance, dynamic, lateral | 22 µm/mN |
| Stylus type | Nude Shibata |
| Stylus tip radius | r/R 6/50 µm |
| Cantilever material | Boron |
| Tracking force range | 1.5-1.7 g (15-17 mN) |
| Tracking force, recommended | 1.6 g (16 mN) |
| Tracking angle | 20° |
| Internal impedance, DC resistance | 1.2 kOhm |
| Internal inductance | 630 mH |
| Recommended load resistance | 47 kOhm |
| Recommended load capacitance | 150-300 pF |
| Cartridge colour, body/stylus | Black/Black |
| 2M Premounted cartridge weight | 16.7 g |
